Offer #426
High Precision Gear Hobber KOLOMNA mod. 5343
YOM: 1969
Country of Origin: Russia
Manufacturer: Kolomna
Specification:
Diameter of workpiece:
-Min: 500 mm
-Max: 3200 mm
Table diameter: 2800 mm
Max module:
-Gear worm: 26
-Gear plate: 30
Max gear length: 425 mm
Distance axis cutter-axis table: 300x2150 mm
Distance axis cutter table surface: 700x100 mm
Max workpiece weight: 40000 kg
Max corner of an inclination of a tooth: 45 degree
Number of hobbing spindle revolution (stepless control): 100 rev/mm
Horizontal feed number: 18
Vertical feed number with plate gear: 15
Main motor power: 25 kW
Dimension:
-Length: 9570mm
-Width: 3780mm
-Height: 5170mm mm
Machine weight: 84000 kg
