Roll grinding machine XSH5-06M

Offer #1683

Roll grinding machine XSH5-06M
Manufacturer: Kharverst
Made in: Ukraine

Designed for external grinding of cylindrical, conical, convex and concave surfaces of rolls and shafts.

Specification:

Work-piece diameter: 2000 mm
Work-piece length: 12000 mm
Work-piece weight: up to 60000 kg
Height of centers: 670 mm
Longitudinal carriage travel: 11000 mm
Grinding wheel diameter: 450-600 mm
Motor power: 70 kW
Overall machine dimensions:
 -Length: 20620 mm
 -Width: 6000 mm
 -Height: 4066 mm
Machine weight: 80000 kg
