Surface grinder OKAMOTO CNC-63

Offer #1187

Surface grinder OKAMOTO CNC-63
YOM: 1986
Manufacturer: OKAMOTO MACHINE TOOL WORKS LTD.
Made in: Japan

Specification:

CNC control: FANUC System 6M

CAPACITY
Tabie working surface (WxL): 300x600 mm
Table maximum travel: 330x800 mm
Maximum distance under 305 mm dia. wheel to table: 347.5 mm
Dimemsion of standart magnetic chuck: 300x600x108 mm
Maximum permissible weight on table including chuck and wheel dresser: 600 kg

TABLE LONGITUDINAL FEED
T-slot (No. x Width): 3 x 17 mm
Longitudinal feed (hydraulic): 0.5-25 m/min
Hand feed per revolution: 69 mm

TABLE CROSS FEED
Least input increment: 0.001 mm
Feed rate (Tape): 1-250 mm/min
Override: 0-200
Rapid feed: 500 mm/min
Manual feed by pulse generator: 0.001 mm/pulse
Manual continuous feed by jogging lever: 400 mm/min

WHEEL VERTICAL FEED
Least input increment: 0.001 mm
Feed rate (Tape): 1-250 mm/min
Override: 0-200
Rapid feed: 500 mm/min
Manual feed by pulse generator: 0.001 mm/pulse
Manual continuous feed by jogging lever: 400 mm/min
Number of sparkout times: 0-16 times

GRINDING WHEEL
Outside diameter x width x bore: 305 x 50x 76.2 mm
Speed (Infinitely variable): 500-3500 rpm

ELECTRICAL MOTORS
Wheel spindle: 3.7 kW
Hydraulic pump: 2.2 kW
Coolant system with a paper filter (option): 0.22 kW
Oil temperature regulator (option): 0.75 kW + 0.4 kW + 1 kW

FLOOR SPACE
Length: 4150 mm
Width: 3020 mm
Height: 2430 mm

Weight: 3000 kg
