Thread and worm grinder MIKROMAT GSU 315x500

Offer #829

Thread and worm grinder MIKROMAT GSU 315x500
Manufacturer: MIKROMAT
Made in: Germany

Specification:

Grinding diameter:
  -Max: 315 mm
  -Min: 2 mm
Max grinding length:
  -With wheel of 50 mm width: 500 mm
  -With wheel of 8 mm width: 550 mm
Max work-piece weight: 160 kg
Distance between centers: 800 mm
Max component length inserted in a work-piece spindle: 760 mm
Spindle bore: 40 mm
Spindle taper (metrical): 80 mm
Max lifting angle: +-40 degrees
Grinding wheel diameter:
  -Max: 500 mm
  -Min: 360 mm
Grinding wheel width:
  -Max: 50 mm
  -Min: 8 mm
Central hole of the grinding wheel: 203 mm
