Hydro-forming press SIEMPELKAMP mod. IHU 1600

Offer #1836

Hydro-forming press SIEMPELKAMP mod. IHU 1600
YOM: 1995
Manufacturer : SIEMPELKAMP
Made in: Germany

It is in excellent condition.

Specification:

Total pressure force: 16000 kN
Tool height: 400 mm
Height: 1500 mm
Stand width: 2050 mm
Tables: 2 x 1000 x 1300 mm
1 x 2000 bar pressure intensifier
Max. hold-down pressure: 16000 kN
Press stroke: 1100 mm
Max. lowering speed in the stand-alone: 600 mm/s
Max. lowering speed coupled operation: 300 mm/s
Max. speed of retreat in the individual operation: 640 mm/s
Max. retreat speed coupled: 320 mm/s
Axial forming cylinder: 2 St
Max. hydraulic pressure: 330 bar
Installed drive power: 230 kW
Total weight according to manufacturer: about 155,000 kg

Description:

ALL forming of internal high-pressure forming make SIEMPELKAMP year 1995.
Both cylinders were about 3 years ago overhauled.
