Universal lathe GILDEMEISTER NEF 400

Offer #786

Universal lathe GILDEMEISTER NEF 400
YOM: 2007
Control system: SIEMENS 840 D

Machine is in a good technical condition.
Spindle operating time: about 2.000 hours
Machine operating time: only 4.000 hours

Specification:

Working area:
 -Max swing diameter over bed: 385 mm
 -Max turning diameter over bed: 350 mm
 -Max turning diameter over cross slide: 350 mm
 -Cross travel (X): 255 mm
 -Longitudinal travel (Z): 800 mm
Diameter of the processing: 350 mm
Length of the processing: 650 mm
Spindle speed range: 0-4.500 rpm
Spindle bore diameter: 65 mm
Tool changer: 8 tools, driving tailstock, chip blower
Complete spare parts: tool holders, collet sets
Chunk: SCHUNK ROTA NCWF 210-52 (new one costed over 4000,00 Еuro)
Main spindle:
 -Spindle head: 170 h5 Size
 -Bar capacity (for power chuck): 65 mm
 -Diameter in the front bearing: 130 mm
 -Chuck diameter: 200 mm
 -Drive output (40/100 % DC): 11.5 kW
Machine dimensions (LxH): 4165x2272 mm
Machine weight: 3700 kg
