Vertical turret lathe KOLOMNA KU64F1

Offer #1636

Vertical turret lathe KOLOMNA KU64F1
YOM: 1966
Manufacturer: KOLONNA
Made in: Russia

Specification:

Max. work-piece dimensions:
 -Diameter: 6300 mm
 -Height: 5000 mm
Max. work-piece weight: 160000 kg
Table faceplate diameter: 6300 mm
Max. vertical movement of:
 -Cross-piece: 2800 mm
 -Slides of two upper supports: 2500 mm
Max. transversal movement of upper supports: 3720 mm
Max. turn angle of supports: -15...+30 deg
Max. cutting force on support:
 -Right: 10 tons
 -Left: 8 tons
Max. faceplate torque: 40000 kgm
Faceplate rotation frequency (stepless adjustment): 0,28-25,5 rpm
Vertical and transversal feeds of supports (stepless adjustment): 0,0352-285 mm/min
Speed of:
 -Rapid movement of slide and supports: 2400 mm/min
 -Cross-piece movement: 300 mm/min
Voltage: 380 V, 50 Hz
Nominal current: 600 A
Main electric motor power: 180 kW
Machine dimensions:
 -Length: 8212 mm
 -Width: 14200 mm
 -Height (total): 12250 mm
 -Height above floor level: 10010 mm
Machine weight: 243400 kg
