Screw press WEINGARTEN PZS 630

Offer #1909

Screw press WEINGARTEN PZS 630
Manufacturer: Maschinenfabrik Weingerten AG
Made in: Germany
Nominal striking force: 4000 tons
Gross potential enerergy: 100000 mkp
Number of strokes per minute: 14-18
Min. spindle diameter: 630 mm
Max. stroke: 750 mm
Min. stroke: 280 mm
Stroke for obtaining max. capacity: 750 mm
Impact speed: 600 mm/sec
Distance between table and ramL
 -Stroke down: 1200 mm
 -Stroke up: 1950 mm
Width between uprights:
 -Below guideways: 1650 mm
 -In between guideways: 1150 mm
Table clamping surface (width x depth): 1600 x 1400 mm
Ram clamping surface (width x depth): 1300 x 1400 mm
Power requirement: 860 kW
Idling speed of motor: 600 rpm
Machine height above floor: 8200 mm
Net weight of complete machine: 310 tons
